Name: Precision Meter 8-Shape Processor WPM-CPRT81TH
Brand: JINGWEI
SKU: WPM-CPRT81TH
Price: 1000.00 USD
Availability: InStock
Rating: 4.8 (89 reviews)

Precision Meter 8-Shape Processor WPM-CPRT81TH

Precision Meter 8-Shape Processor WPM-CPRT81TH
Model No: WPM-CPRT81TH
The Precision Meter 8-Shape Processor WPM-CPRT81TH combines precise wire metering with figure-8 coiling. This machine ensures accurate wire lengths and organized figure-8 coils, ideal for applications requiring precise wire lengths and efficient cable management.
Inquiry now

Detailed description

High-end meter precision big 8-word single tie type cutting line peeling winding tie machine WPM-CPRT81TH
Technical parameters:
Applicable wire diameter 6-10mm
Cutting length 1-6m
Cutting line length accuracy: ±15 mm
Winding the appearance of the 8-figure single cable tie
The inner diameter of the circle is 240-260mm (adjustable)
Binding diameter ≤40mm
Desquamation mode complete desquamation at both ends
Head retention length 200-250mm (adjustable)
Head peeling length 17-32mm (adjustable)
Tail length 200-250mm (random value within a range)
Tail skinning length 17-32mm (adjustable)
Production efficiency: 200-400PCS/H (3-14m)
Applicable binding tape: Coated iron core ≤ 7.5kg/roll
Power supply: 240V/50Hz
Machine power: 5KW/H
Machine size: about 3000L*1100W*1850Hmm
Machine weight: about 1200KG
Main accessories:
Cylinder: Yadeke cylinder and solenoid valve
Motor: Winding main servo motor 1000W Turbot
Motor: take line translation servo motor Turbot 1500W
Motor: linear motor module shift servo motor Turbot 750W
Motor: online translation servo motor Dongling 750W
Motor: up and down servo motor dangling 750W
Motor: winding up and down 57 closed-loop mine race
Motor: Twisting and strapping belt spitting belt 57 stepper motor thunder race
Motor: storage tape motor 6W
Slide block: take line translation double slide block linear motor module
Guide rail: lower paw translation double guide rail
PLC: vigor
Screen: Dimension control 7"
Power supply: clear weft
Frame: the iron frame is painted blue and white
Safety protection: stop when the door opens
Lack of material alarm: three-color lamp buzzes
Frame: the iron frame is painted blue and white
Features:
it solves the problem of large inaccuracy tolerance of meter cutting length in the case of figure 8.
A. The product is positioned at high-quality wire manufacturers, suitable for wire harness/hose/rope;
B, high performance, the maximum speed can reach 400 pieces/hour;
C, automatic wire cutting, winding, and tying, saving labor;
D. The finished products after winding and tying are beautiful, generous, tidy, and easy to package to meet the high-quality requirements of customers;
E, small size, no space, save the rent.
F. Easy to operate, debug and maintain;
G, humanized design, greatly reduces staff fatigue intensity and improves work efficiency.
H, the machine adopts programmable controller (PLC) control, man-machine interface control, and automatic uninterrupted operation.
