Detailed description
8-word single tie cable arrangement machines, including automatic cable tying machines, automatic bundling machines, wire/cable bundle tying equipment and wire tying machinery.
Technical parameters:
The number of lines is 15-20
Length of wire 0.6-2m
Winding the appearance of the 8-figure single cable tie
The spacing of winding is 80-200mm
Binding diameter ≤40mm
The retention length of the head is less than or equal to 130mm
Tail length ≤200mm
Production efficiency: ≤1300/H (1-2m)
Applicable binding tape: Coated iron core ≤ 7.5kg/roll
Applicable air pressure: 0.5-0.6mpa
Power supply: NATIONAL standard 220V/50Hz
Machine power: 3.5KW/H
Machine size: about 1200L*1500W*1600Hmm
Machine weight: about 300KG
Main components:
Cylinder: Yadeke cylinder and solenoid valve,
Motor: Winding servo motor 1500W Turbot
Motor: line translation servo motor 750W Turbot
Motor: Feeding belt 57 closed-loop motor lightning race
Motor: Twisted tie belt 57 stepper motor thunder race
Motor: storage tape motor 6W fixed speed
Take line translation: double slider
PLC: vigor
Screen: dimension control 7 inches
Power supply: clear weft
Frame: iron frame, blue and white, painted
