The Steel Rope Meter Coiler WPM-40-80S measures and coils steel rope and cable up to 80mm diameter. This heavy-duty machine ensures accurate lengths and organized coiling for steel rope, enhancing efficiency in steel cable preparation and handling.
Steel wire rope coiling and cutting machine with statistical length measurement, equipped with cable bundling and meter counting function, as well as wire coil winding and binding capabilities. Additionally, it can also be used for cable rewinding.
The outer diameter of the winding dish 350mm
Cutting diameter <8mm
Tying wire length 120-200mm
Cable tie Rubber wrapped iron wire
Suitable coil diameter for tying 18-45mm
Voltage AC220V 50Hz/60Hz
Cable coil diameter 50-280mm
Rated Power <2500W
Winding speed 1-10 sec/circle
Weight 230KG
Dimensions L1000*W450*H800(mm)
Winding tolerance 25mm
Loading weight of winding wire <2.5KG
Efficiency 3*10-meter coils of cable/min without tying
