Middle Strip Wire Stripper WPM-0-4M
Model No: WPM-0-4M
The Middle Strip Wire Stripper WPM-0-4M provides mid-strip capability for wires from 0 to 4mm diameter. This tool allows for precise stripping of wire insulation in the middle of the wire, enabling mid-span connections and specialized wiring configurations.
Inquiry now

Detailed description

wire cutting and stripping machine for middle stripping WPM-0-4M
This machine is mainly suitable for 0.1-4.5mm² smaller wire processing. It can cut the wire into specific lengths, and strip wire insulation at the same time. I can do full-strip, partial-strip, and different part stripping. Its most feature is the middle open window stripping function, it will not slide the wires.
Safety protection.
A plastic Protection shell is available， automatic wire feeding machine is available.
Technical Data
Name Automatic wire cutting and stripping machine
Cutting Length 1-9999mm
Stripping Length Front: 15mm; Rear: 35mm
Voltage 220V/110V
Power Rate 300W
Cutting tolerance (0.2+/- 0.002 by L) mm
Cutting Stripping wire core section 0.1-4.5mm2
Optimal stripped wire: PVC// silica gel line, Glass fiber cables, etc.
The blade material: hard tungsten steel
Output L = 100 mm, 3000 8000 PCS/h (high yield)
Weight 35KG
Dimension 390 x350x255mm
Middle Stripping Machine, Window Stripping Machine, Wire Stripping Machine

Middle Stripping Machine, Window Stripping Machine, Wire Stripping Machine

sample display of Middle Stripping Machine, Window Stripping Machine, Wire Stripping Machine
